SURFACE PREPARATION





#EDC VACUUM LINE



If your jobs involve concrete grinding and surface preparation, chances are that you are aware of the updated OSHA standard 1926.1153 on silica dust containment which is intended to help protect workers from exposure to respirable crystalline silica. This standard specifically defines stringent requirements for vacuum dust collection systems to be used in conjunction with concrete grinding work. OSHA now requires you to use a high-efficiency particulate air (HEPA) filter that is at least 99% efficient in removing mono-dispersed particles.



If you're not using a vacuum that meets these standards, it's time for an upgrade to acquire both regulatory compliant peace of mind AND top performance from an ultra-durable premium vacuum.

The new Taylor Tools line of Extreme Dustmaster dry vacuums meets and exceeds OSHA's new standards. The collection includes three new products: the #EDC.290 10.5 Gallon vac, the #EDC.400 Continuous Bagger vac and the #EDC.75.20 Cyclonic Pre-Separator.



Both of the new dust collectors supply high performance HEPA filtration (99.97% of particles down to 0.3 Microns) and produce a powerful 280 CFM of suction at 110 volts AC with a 100% duty cycle. Each steel-constructed vac features a filter shaker system designed to constantly remove filter buildup. That means Taylor Tools dust collectors are made to operate all day long with consistent performance. Additionally, 32' of siliconized hose length - resistant to kinking and cracking - will help you reliably reach further into your job's square footage.


#EDC.290 Extreme Dustmaster with HEPA Filter
#EDC.400 Extreme Dustmaster Continuous Bag System with HEPA Filter

#EDC.75.20 Extreme Dust Control Cyclonic Pre-Separator

#EDC.280.330.50 Bag Filters (100 bags/case. Fits EDC.290)

#EDC.400.65 Continous Bagging Replacement - 65ft

#485-17 EXTREME MACHINE
17" FLOOR MACHINE



Ideal for Grinding, Sanding, Mastic Removal, Concrete Profiling and More.

The 17-inch Extreme Machine is one of the most durable and dependable floor machines you can find on the market today - go ask someone who has one and be advised to invest in the best. Made entirely from aluminum and steel, this machine shrugs off the abuse of grinding, scarifying and sanding concrete. It is so rugged, the use of EZ Scrape or other grinding attachments WILL NOT VOID THE WARRANTY, unlike other popular buffers.


The Extreme Machine features a triple planetary gear unit with a steel coupling. It has a 1 YEAR WARRANTY on parts and labor. Comes standard with vacuum port. Optional 40 lb Accessory Weight and Dust Control Ring also available.

• Dual safety switch levers
• 1.5 HP, 110V motor. 175 rpm. Weight 102 lbs (w/out accessory weight).
• Totally enclosed external fan prevents concrete dust and grit from entering the motor windings and wearing the motor out
• 50' power cord

• MADE IN THE USA

• CAN BE USED WITH TORQUE GUARD APPLIANCE

#485-17 EXTREME MACHINE
17" FLOOR MACHINE WITH INTEGRATED TORQUE GUARD



The #485 industry workhorse Extreme Machine and economical is now available with integrated Torque Guard  from Taylor Tools.


The 485.17.TG now comes with the Torque Guard integrated into the handle set.

Torque Guard Graphic_cut.png
#TG.2000 TORQUE GUARD



MORE INFORMATION



487.17.00 Green Machine.jpg
#487-17 GREEN MACHINE 17" FLOOR MACHINE





The 17-inch #487 Green Machine from Taylor Tools may look mild mannered but once you turn it on this beast transforms into one hulk of a grinder! This burly and sturdy floor machine features a triple planetary gear unit with a steel coupling and comes standard with vacuum port. Optional 40 lb accessory weight and dust control ring are also available.

The #487 Green Machine includes features such as:

  • 1.5hp AC motor,175 rpm head speed

  • Dual safety switch levers

  • Beefy, oversized handle and shaft tubes

  • Cast aluminum base & switchbox

  • Reinforced transportation wheels

  • CAN BE USED WITH TORQUE GUARD APPLIANCE



Floor Prep Plus 490.17.G2.jpg
#491.17 FLOOR PREP PLUS
17" FLOOR MACHINE



The second generation Floor Prep Plus grinder is now all steel construction with a myriad of features including:

  • Triple-planetary gear box (165 RPM) with steel drive coupler for use as a grinder

  • Approved for EZ Scrape attachments

  • Vacuum port standard

  • Dust containment shroud attachment available

  • 1.5 HP Extreme Heavy Duty Motor

  • 115 volts 60 Hz

  • 50 ft. x 14-3 power cord

  • All steel construction

  • Ball bearing non-marking wheels

  • MADE IN THE USA

  • 112 lbs

  • Optional 40 lb weight kit and Dust Control Ring also available

  • CAN BE USED WITH TORQUE GUARD APPLIANCE

#483 COMMERCIAL BUFFER



The #483 commercial buffer is the ideal machine for applications such as floor scrubbing, finish stripping and light buffing. This buffer shares many of the same new features with the Floor Prep Plus grinder including:



  • "safe start" power indicator. Won't run away on startup!

  • Ergonomic, easy to reach handle adjustments

  • 1 year warranty

  • Wrap around cord clamp and strain relief

  • Assembled in the USA

100.00.00 Mixing Station 2.png
#100 MIXING STATION


The #100 mixing station from Taylor Tools makes it possible to mix and apply up to 165 lbs. of leveling compound at a time in a fast and effective way. The mixing station base is incredibly well-balanced, thus making it easy to move. The holder for the mixing station is easily attached to the edge of the barrel. The height of the holder and the width of the locking sleeve mount can be adjusted in order to fit all mixers. Obtain a dust free stirring by attaching the hose holder to the edge of the barrel. The 20 gallon barrel is produced of high quality plastic that ensures a long lifetime. The turbine stirrer is designed specifically for this mixing station.

The Taylor Tools mixing station consists of:

  • Trolley Base

  • 20 gal. Mixing Barrel

  • Holder for Stirring Machine

  • Hose Holder / Dust Extractor

#470 EZ SCRAPE
Removes cutback, multi-purpose adhesives and other hard-to-remove floor residue quickly and easily. The EZ Scrape consists of six carbide blades (3 more than previously) spring mounted on an aluminum casting which fits 175 RPM rotary disk floor machines. There are three different models to accommodate different diameter machines.

#471 - 15" disk for 17" machines
#470 - 17" disk for 19" & 20" machines


471 EZ Scrape .png


Features:
• No messy chemicals or disposal problems. The EZ Scrape is a dry removal system. The rotating steel blades reduce floor accumulations (even painted lines) to dry, sweepable dust. There is no chemical waste to dispose of.
• No "downtime" waiting for the floor to dry. After sweeping away the residue, you're ready to start installing the new floor.
• Incredibly fast.
• Eight-sided blades assure long life.
• One year warranty on parts and labor.

GRINDER/BUFFER
ATTACHMENTS & ACCESSORIES

More Info
